BriteX Brightness Sensor

brightness sensor

BriteX Brightness Sensor

  • 99 levels of relative brightness scale
  • Detection range up to 1000mm
  • High resolution analog output
  • Calibration option

$1,039.99$2,499.99

Clear
SKU : N/A Categories : , ,

BriteX Brightness Sensor OVERVIEW

The BriteX™ brightness sensor employs our field-proven, patented technology to provide a simple solution for on-line monitoring and detection of a wide variety of materials in manufacturing and packaging applications. Our brightness sensors can detect differences in color, brightness, and surface texture at a lower cost than competing products making them an ideal solution for multi-point sensing applications. BriteX brightness sensors improve process control by allowing more measurement points for real-time process feedback. Tighter control of processes can reduce operating costs and minimize quality variations.

The BriteX sensor measures relative brightness defined by ISO 2470 as a reflectance factor of diffused blue light at 457nm. The BriteX features a 2-digit display that provides an indication of signal strength, making set-up and integration quick and easy. The versatile sensor provides user set-up parameters including light source intensity adjustment, detection threshold, and gain selection.

Brightness Sensor Applications:

  • Paper
  • Pulp
  • Rice
  • Gypsum
  • Sugar



Sensor Variations

  • BriteX-1000P™ – For in-line process control of paper brightness, paper bleaching, and de-inking, paper grading, and textile applications
  • BriteX-1000S™ – Effective reflectance measurements of raw or refined ICUMSA* sugar color on-line using field-proven, patented technology.



*ICUMSA Limited has not set a specification for the BriteX technology. ICUMSA Limited has not reviewed and therefore does not endorse BriteX technology. It is ICUMSA Limited’s policy to not endorse any proprietary equipment or manufacturer.



Have Questions? Click Here

FEATURES WITHIN OUR BRIGHTNESS SENSOR

  • Numerical display in standard brightness units
  • Several times the range of competing sensors
  • Adjustable sensitivity
  • Variable projected-light intensity enables flexible operation over wide range of distances and materials
Model Number BriteX-100 BriteX-1000P BriteX-1000S
Application Optimized for small target areas Dry end paper ICUMSA sugar
Display Range 0-99 0-99 0-99
Spot Size 8mm 50mm 50mm
Operating Range up to 150mm up to 900mm up to 900mm
Discrete Output PNP/NPN PNP/NPN PNP/NPN

BriteX Brightness Sensor – Detecting Transparent Tape

See how the BriteX brightness sensor can easily verify the presence of transparent tape in automated packaging applications.

BriteX Sensor – Sugar Color with Relative ICUMSA Values

The BriteX-1000S™ sensor displays the relative ICUMSA values of sugar color allowing seamless measurement, monitoring, and if needed, adjustment.
