LEX-1000 RGB Light Sensor

LEX-1000 COLOR LIGHT MEASUREMENT SENSOR

LEX-1000 RGB Light Sensor

  • High sensitivity and high resolution
  • PC-based configuration software
  • USB/RS232 interface
  • Analog outputs (RGB)

$999.99

Current lead time is 2-3 weeks to ship

SKU : EMX-1010-1 Categories : , ,

LEX-1000 RGB Light Sensor Overview

The LEX-1000 RGB light sensor is designed to measure relative color characteristics of a wide variety of light sources or illuminated objects by separating the light into its red, green, and blue components. The LEX –1000 is the perfect solution for monitoring processes that involve light, performing comparative quality measurements on light-emitting devices, or any process where a comparative light measurement is necessary.

The sensor optics collect light and focuses this light onto a sensitive receiver element. The sensor analyzes the light for its constituent RGB (red, green, blue) values. If the readings of all of the three colors fall within the preprogrammed parameters, the sensor issues a discrete signal that indicates a color match. Highspeed discrete outputs provide a standard interface to factory automation systems. The LEX-1000 provides four programmable color recognition channels, RGB analog outputs, and serial communications via RS232 or USB.

For light measurement, see our LEX-100 Light Sensor.

Color Light Measurement Sensor Applications:

  • Evaluation of all visible light sources
  • Comparative light measurement
  • Relative color measurement
  • LCD and LED display quality
  • Automotive lighting verification



Software

ColorMax Windows™ Application Program provides a comprehensive approach to sensor set-up, file management, and real-time sample analysis and evaluation.

Have Questions? Click Here

Color Light Measurement Sensor Features

  • High resolution
  • Four programmable color recognition channels
  • High-speed discrete outputs provide standard interface to factory automation systems
  • RGB analog outputs
  • Serial communications via RS232 or USB
  • Easy set up with PC-based configuration software
  • Lock out operator from changing settings
  • Exclusive M30 housing provides robust construction for industrial environments
Model Number LEX-1000
Color Channels 4
RGB Analog Outputs yes
Serial Data Output yes
Operating Range 50-600mm
Discrete Output PNP/NPN

Industrial Light Source RGB Analysis

The LEX-1000 RGB Light Sensor measures the relative color characteristics of a wide variety of light sources and illuminated objects.
